GENERAL INFORMATION :
Manufacturer: Hewlett Packard
Manufacturer Part Number: 732342-001
Product Name: Proliant Dl560 Gen8 2u Rack Mount (Performance Model)
PROCESSOR & CHIPSET :
Processor Type : Intel Xeon E5-4640v2 /2.2GHz
Multi-Core Technology : 10 Core
64 Bit Computing : Yes
Installed Qty : 4
Max Supported Qty: 4
Upgradability : Upgradable
Processor Main Features : Intel Quickpath Interconnect
Chipset Model : Intel C600
CACHE MEMORY :
Cache Memory Type : L3 Cache
Installed Size : 80 Mb
Cache Per Processor : 20 MB
MEMORY :
Installed Size : 128 Gb / 768 Gb (Max)
Technology : Ddr3 Sdram
Memory Speed : 1866 Mhz
Memory Specification Compliance : Pc3-14900
Form Factor : Dimm 240-Pin
Features : Registered, Hp Smartmemory
Configuration Features : 16 X 8gb
Ram Supported :
Pc3-14900 – 768 Gb – Registered
Pc3-12800 – 768 Gb – Low Voltage – Registered
Pc3-14900 – 1536 Gb – Load-Reduced
STORAGE & STORAGE CONTROLLERS :
Hard Drives : None Ship Standard
Type : 1 X Raid – Integrated – Pci Express 3.0 X8
Controller Interface Type : Sata 6gb/S / Sas 6gb/S
Storage Controller Name : Smart Array P420i With 2gb Fbwc
Channel Qty : 8
Raid Level : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60
Buffer Size : 2 GB
DISPLAY & GRAPHICS :
Graphics Controller Manufacturer: Matrox
Graphics Controller Model: G200
NETWORK & COMMUNICATION :
Type : Plug-In Card
Ethernet Ports : 2 X 10 Gigabit Ethernet
Ethernet Controller : Hp 533flr-T
Data Link Protocol : 10 Gigabit Ethernet
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol), Pxe Support
