GENERAL INFORMATION :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 783359-S01-RF
Product Name : Proliant Dl160 Gen9 1u Rack Mount S-Buy Base Model
PROCESSOR & CHIPSET :
Processor Type : Intel Xeon E5-2620V3 / 2.4 Ghz
Number Of Cores : Hexa-Core (6 Core)
64-Bit Computing : Yes
Installed Qty : 1
Max Supported Qty : 2
Upgradability : Upgradable
Chipset Type : Intel C610
CACHE MEMORY :
Cache Memory Type : L3 Cache
Installed Size : 15 MB
Cache Per Processor : 15 MB
MEMORY :
Installed Size : 16 Gb
Maximum Size : 512 Gb
Technology : Ddr4 Sdram
Memory Speed : 2133 Mhz
Memory Specification Compliance : Pc4-17000
Form Factor : Dimm 288-Pin
Memory Slots: 16 x DDR4 RAM Slots
Features : Registered, Hp Smartmemory
Configuration Features : 2 X 8 Gb
Ram Supported : Pc4-17000 – 256 Gb – Registered, Pc4-17000 – 512 Gb – Load-Reduced
STORAGE & STORAGE CONTROLLER :
Hard Drive : None
Storage Controller Type : 1 X Raid – Integrated
Controller Interface Type : Sata 6gb/S
Storage Controller Name : Hp Dynamic Smart Array B140i
Channel Qty : 8
Raid Level : RAID 0, RAID 1, RAID 5
DISPLAY & GRAPHICS CONTROLLERS :
Graphics Controller Type : Integrated
Graphics Processor : Matrox G200eh2
NETWORK & COMMUNICATION :
Networking : Network Adapter – Integrated
Interface (Bus) Type : Pci Express 2.0 X2
Ethernet Ports : 2 X Gigabit Ethernet
Ethernet Controller(S) : Hp Nc361i
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol), Pxe Support
Compliant Standards : IEEE 802.3, IEEE 802.3U, IEEE 802.3AB, IEEE 802.1AS, IEEE 802.3AZ
EXPANSIONS & CONNECTIVITY :
Expansion Bays Total (Free) :
1 (Total) / 1 (Free) X Front Accessible – 5.25in Slim Line
8 (Total) / 8 (Free) X Hot Swap – 2.5in Sff
EXPANSION SLOTS TOTAL (FREE) :
16 (Total) / 14 (Free) X Memory – Dimm 240-Pin
2 (Total) / 1 (Free) X Processor
1 (Total) / 1 (Free) X Pci Express 3.0 X16 – Full-Length, Full-Height
1 (Total) / 1 (Free) X Pci Express 3.0 X8 – Low-Profile
1 (Total) / 1 (Free) X Microsd Card (Internal)
INTERFACES & PORTS :
1 X Display / Video – Vga
2 X Network – Ethernet 10base-T/100base-Tx/1000base-Tx – Rj-45
1 X Management – Hp Ilo – Rj-45
1 X Usb 2.0 ( 1 In Front )
3 X Usb 3.0 ( 2 Rear, 1 Internal )
POWER DEVICE :
Device Type : Power Supply
Voltage Required : Ac 120/230 V ( 50/60 Hz )
Power Provided : 550 Watt
DIMENSIONS & WEIGHT :
Width : 17.1 In
Depth : 23.9 In
Height : 1.7 In
Weight : 22 Lbs
