GENERAL INFORMATION :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 792468-S01
Product Name : Proliant DL380 Gen9 – 2U Rack Mount Server (S/Buy)
PROCESSOR & CHIPSET :
Processor Type : Intel Xeon E5-2650V3/ 2.3GHz
Max Turbo Speed : 3 GHz
Quickpath Interconnect : 9.60 GT/S
Number Of Cores : 10 Core
64-Bit Computing : YES
Compatible Processor Socket : FCLGA2011-3
Installed Qty : 2
Max Supported Qty : 2
Chipset Type : Intel C610 Series
CACHE MEMORY :
Cache Memory Type : Smart Cache
Installed Size : 25MB
MEMORY :
Installed Size : 32 GB / 384 GB (MAX)
Technology : DDR4 SDRAM – ADVANCED ECC
Memory Speed : 2133 MHz
Memory Specification Compliance : PC4-17000
Form Factor : DIMM 288-PIN
Memory Slots: 24 x DDR4 RAM Slots
Features : Registered, Online Spare Memory, Quad Channel Memory Architecture, Hp Smart memory
Configuration Features : 4 X 8 GB
RAM Supported : PC4-17000 – 384 GB – Registered ¦ PC4-17000 – 1.5 TB – Load-Reduced
STORAGE & STORAGE CONTROLLER :
Hard drive Type : Hdd – Hot Swap
Capacity : 4 X 600 GB
Interface Type : SAS 6GB/S
Spindle Speed : 10000 RPM
Hard Drive (2nd) :
Type : Hdd – Hot-Swap
Capacity : 2 X 300 GB
Interface Type : SAS 6GB/S
Spindle Speed : 10000 RPM
Optical drive type : none.
STORAGE CONTROLLERS:
Storage Controller Name : Smart Array P440ar
Buffer Size : 2 GB
Disk Drive : 12GB/S SAS / 6GB/S SATA
Sas Port Link Rate : 12GB/S Per Physical Link Supported
Pcie Link Rate : Pci Express 3.0 X8 (PCIE3 X8)
Physical Drives : Up To 26 Drives
Logical Drives Supported : UP TO 64 LOGICAL DRIVES
Raid Support : RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Display & graphics controllers :
Graphics Controller Type : Integrated Matrox G200eh2
NETWORK & COMMUNICATION:
Ethernet Controller : Hp Ethernet 1gb 4-Port 331i Adapter
Network Processor : Broadcom Bcm5719 Chipset
Ethernet Ports : 4 X Gigabit Ethernetduplex Theoretical Bandwidth
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : Integrated Lights-Out 4
Remote Management Controller : Rj-45 (Two)
Features : Wake On Lan (Wol), Pxe Support
Compliant Standards : IEEE 802.3, IEEE 802.3U, IEEE 802.3AB
POWER DESCRIPTION :
Device Type : Flex Slot Platinum Plus Hot-Plug Power Supply
Installed Qty : 2
Max Supported Qty : 2
Nominal Voltage : AC 100-240V (50/60 HZ)
Power Provided : 800 WATT
Expansion/ connectivity :
Expansion bays total (free) :
24 (TOTAL) / 18 (FREE) X HOT-SWAP 2.5 SFF
EXPANSION SLOTS TOTAL (FREE) :
24 (TOTAL) / 20 (FREE) X DIMM 288-PIN
2 (TOTAL) / 0 (FREE) X CPU
2 (TOTAL) / 2 (FREE) X PCIE 3.0 X16 – HALF-LENGTH, FULL-HEIGHT ( X8 MODE )
1 (TOTAL) / 1 (FREE) X PCIE 3.0 X8 – HALF-LENGTH, FULL-HEIGHT
1 (TOTAL) / 1 (FREE) X MICROSD CARD (INTERNAL)
INTERFACES & PORTS :
4 X LAN (GIGABIT ETHERNET) – RJ-45
1 X HP ILO – RJ-45
1 X VGA
5 X USB 3.0 (1 FRONT, 2 REAR, 2 INTERNAL)
