General Information :
Manufacturer: IBM Corporation
Manufacturer Part Number: 86821RY
Product Name: Netfinity 6000r Tower Server
Processor & Chipset:
Processor Type : Intel Pentium Iii Xeon 700 Mhz.
Installed Qty : 1
Max Supported Qty : 4
Upgradability : Upgradable.
Data Bus Speed : 100 Mhz.
Ram & Cache Memory:
Installed Size : 512 Mb / 16 Gb (Max).
Technology : Sdram – Ecc.
Memory Speed : 100 Mhz.
Form Factor : Dimm 168-Pin.
Features : Registered.
Upgrade Rule : 4 Modules At A Time.
Cache Memory Type : L2 Cache – Advanced Transfer Cache.
Installed Size : 1 Mb (Installed) / 4 Mb (Max).
Storage :
Hard Drive : None.
Hard Drive (2nd): None.
Floppy Drive : 3.5 1.44 Mb Floppy.
Optical Storage Type : Cd-Rom – Ide.
Read Speed : 40x
Storage Controllers:
Media Load Type : Tray.Storage Controller Type : 1 X Scsi – Integrated – Pci.
Controller Interface Type : Ultra160 Scsi.
Channel Qty: 2
Storage Controller Type(2nd) : 1 X Ide – Integrated – Pci.
Controller Interface Type : Ide.
Channel Qty : 2
Display & Graphics Controller :
Graphics Controller Type : Pci – Integrated.
Graphics Processor : S3 Savage4.
Video Memory : Sdram.
Installed Size : 8 Mb / 8 Mb (Max).
Supported Display Graphics : Vga (640×480), Xga (1024×768), Svga (800×600), Sxga (1280×1024)
Video Output Supported: Rgb
Networking :
Networking : Network Adapter – Pci – Integrated.
Data Link Protocol : Ethernet, Fast Ethernet.
Compliant Standards : Ieee 802.3, Ieee 802.3
Power:
Device Type : Power Supply – Hot-Plug.
Power Redundancy : Optional.
Installed Qty : 1
Max Supported Qty : 3
Voltage Required : Ac 110/220 V ± 10% ( 50/60 Hz )
Power Provided : 270 Watt
Compliant Standards : Epa Energy Star
