Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks ACX Series
Model :2100
Packaged Quantity :1
Modem
Type :None
Line Properties
Line Rate :T-1/E-1
Networking
Type :Router
Form Factor :Rack-mountable
Connectivity Technology :Wired
Data Link Protocol :Fast Ethernet, Gigabit Ethernet, TDM, Ethernet
Routing Protocol :MPLS
Remote Management Protocol :CLI, SNMP 2, SNMP 1, SNMP 3
Data Transfer Rate :60 GBps
Features :Call Admission Control (CAC), Class of Service (CoS), Fanless, Precision Time Protocol (PTP)
Compliant Standards :IEEE 1588-2008, MEF 14, MEF 21, G.703, MEF 9
Interface Provided
Interfaces :Alarm: 4 x input, 2 x 10Gb Ethernet – SFP+, 16 x T1/E1 – RJ-48, 8 x 10Base-T/100Base-TX/1000Base-T – RJ-45, Management: 1 x console, 6 x SFP (mini-GBIC), Alarm: 4 x output, Serial: 1 x RS-232
Power Device
Type :Internal power supply
Power Redundancy :Yes
Installed Qty :2
Max Supported Qty :2
Nominal Voltage :AC 120/230 V
Power Consumption Operational :60 watt
System Requirements
OS Required :JUNOS
Miscellaneous
Color Category :Gray
Height (Rack Units) :1
Compliant Standards :FCC Part 15 A, EN 61000-4-3, EN 61000-4-4, EN55022 Class A, EN 61000-4-2, EN 61000-3-3, ETS 300 753, EN 60950-1, TBR12, TBR13, R&TTE, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60825-1, JATE, FCC Part 68, EN 61000-3-2, EN 61000-4-6, TBR21, ETSI, IEC 60950-1, NEBS, CISPR 22 Class A, CS-03, VCCI Class B ITE, EN 61000-4-11, CAN/CSA-C22.2 No. 60950-1
Dimensions & Weight
Width :17.5 inch
Depth :9.4 inch
Height :1.7 inch
Weight :8.31 lbs
Environmental Parameters
Min Operating Temperature :-40 degree Fahrenheit
Max Operating Temperature :149 degree Fahrenheit
Humidity Range Operating :0 – 95% (non-condensing)
