Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks ACX Series
Model :2200
Packaged Quantity :1
Modem
Type :None
Networking
Type :Router
Connectivity Technology :Wired
Data Link Protocol :Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet, Fast Ethernet
Routing Protocol :MPLS
Remote Management Protocol :SNMP 1, SNMP 3, SNMP 2, CLI
Key Features :VPN support
Features :Timing support, Call Admission Control (CAC), VPN support, High Availability, Class of Service (CoS)
Compliant Standards :G.703
Interface Provided
Interfaces :8 x 10Base-T/100Base-TX/1000Base-T – RJ-45, 6 x 1000Base-X – SFP (mini-GBIC), 2 x 10Gb Ethernet / 1Gb Ethernet – SFP+
Power Device
Type :Internal power supply
Installed Qty :2
Max Supported Qty :2
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Power Consumption Operational :60 watt
System Requirements
OS Required :JUNOS
Miscellaneous
Color Category :Gray
Height (Rack Units) :1
Compliant Standards :FCC Part 15 A, CISPR 22 Class A, EN 60825-1, VCCI Class B, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 61000-4-2, ETSI, EN 61000-3-3, EN 61000-4-11, EN 61000-4-3, R&TTE, GR-1089-CORE, EN55022 Class A, EN 61000-4-6, IEC 60950-1, JATE, EN 61000-4-5, CS-03, GR-63-CORE, NEBS level 3, EN 60950-1, TBR13, TBR21, FCC Part 68, TBR12, EN 61000-4-4, ETS 300 753, CB, EN 61000-3-2, CAN/CSA-C22.2 No. 60950-1
Dimensions & Weight
Width :17.5 inch
Depth :9.4 inch
Height :1.7 inch
Weight :8.31 lbs
Environmental Parameters
Min Operating Temperature :-40 degree Fahrenheit
Max Operating Temperature :149 degree Fahrenheit
Humidity Range Operating :0 – 95% (non-condensing)
