Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks ACX Series
Model :500-O-POE
Packaged Quantity :1
Modem
Type :None
Networking
Type :Router
Form Factor :Wall-mountable, Pole-mountable
Connectivity Technology :Wired
Data Link Protocol :Gigabit Ethernet
Routing Protocol :MPLS
Remote Management Protocol :SNMP 3, SNMP 2, SNMP 1, CLI
Features :Call Admission Control (CAC), Class of Service (CoS), PoE++, Timing support, Precision Time Protocol (PTP), PoE+
Compliant Standards :IEEE 802.3ah, IEEE 802.1ag, ITU-T Y.1731, G.703
Interface Provided
Interfaces :3 x 1000Base-X – SFP (mini-GBIC), 3 x 1000Base-T (PoE+) – RJ-45
Power Device
Type :Internal power supply
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Power Consumption Operational :135 watt
System Requirements
OS Required :JUNOS
Miscellaneous
Color Category :White
Compliant Standards :CAN/CSA C22.2 No. 60950-1, EN 61000-4-3, ETS300019-2-1 Class T1.2, EN 61000-4-11, CB, EN55022 Class A, GR-1089-CORE, TBR12, EN 61000-4-6, EN 61000-3-3, JATE, EN 60825-1, TBR21, EN 61000-4-5, ETS300019-2-3, GR-63-CORE, IP65, NEBS level 3, CISPR 22 Class A, EN 61000-4-2, IEC 60950-1, UL 60950-1, ETS 300 753, FCC Part 68, EN 60950-1, R&TTE, FCC Part 15 A, EN 61000-3-2, TBR13, CS-03, VCCI Class B, ETS300019-2-2 Class T2.3, EN 61000-4-4, CAN/CSA-C22.2 No. 60950-1
Dimensions & Weight
Width :10 inch
Depth :4.7 inch
Height :16 inch
Weight :18.7 lbs
Environmental Parameters
Min Operating Temperature :-40 degree Fahrenheit
Max Operating Temperature :149 degree Fahrenheit
Humidity Range Operating :0 – 95% (non-condensing)
