Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks EX 2200
Model :48P
Packaged Quantity :1
Chassis
Built-in Devices :Status LCD
Processor
Clock Speed :800 megahertz
RAM
Installed Size :512 megabyte
Flash Memory
Installed Size :1 GB
Performance
Performance :Throughput: 77 Mpps
Networking
Type :Switch
Subcategory :Network hubs and switches
Subtype :Gigabit Ethernet
Form Factor :Desktop
Ports Qty :48
Advanced Switching :Layer 3
Routing Protocol :RIP-2, IGMP, RIP-1
MAC Address Table Size :8K entries
Manageable :Yes
Remote Management Protocol :HTTP, SNMP 1, HTTPS, SSH-2, RMON 3, SNMP 2c, SNMP 3, RMON 9, RMON 2, Telnet, RMON 1, TFTP
Power Over Ethernet (PoE) :PoE+
PoE Budget :405 watt
Status Indicators :LCD display
Features :Redundant trunk group (RTG), Jumbo Frames support, DHCP server, ARP support, Store and forward, Layer 2 switching, RARP support, Auto-uplink (auto MDI/MDI-X), Per-VLAN Spanning Tree (PVST), Rapid Spanning Tree Protocol (RSTP) support, VLAN support, IGMP snooping, SNTP support, DiffServ support, Layer 3 switching, Flow control, Quality of Service (QoS), Temperature sensor, BOOTP support, Trivial File Transfer Protocol (TFTP) support, Multiple Spanning Tree Protocol (MSTP) support, DoS attack prevention, Time Domain Reflectometry (TDR)
Compliant Standards :IEEE 802.3z, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3u, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.1p
Ports
Qty :48
Type :10/100/1000 (PoE+)
Ports (2nd)
Qty :4
Type :Gigabit SFP
Interface Provided
Interfaces :1 x console RJ-45 management, 4 x Gigabit LAN SFP uplink, 48 x 1000Base-T RJ-45 PoE+, 1 x 100Base-TX RJ-45 management, 1 x USB Type A
Power Device
Type :Internal power supply
Power Consumption Operational :91 watt
Miscellaneous
Height (Rack Units) :1
Authentication Method :Extensible Authentication Protocol (EAP), TACACS+, RADIUS
Compliant Standards :EN55024, CSA C22.2 No. 60065, VCCI Class A ITE, cUL, EN 300 386, UL 60950-1, RoHS 6/6, UL, CISPR 22 Class A
Dimensions & Weight
Width :17.4 inch
Depth :10 inch
Height :1.8 inch
Weight :9.92 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :113 degree Fahrenheit
Humidity Range Operating :10 – 85%
