Environmental Parameters
Humidity Range Operating :5 – 95% (non-condensing)
Max Operating Temperature :113 °F
Min Operating Temperature :32 °F
Header
Brand :Cisco Meraki
Manufacturer :CISCO DS HARDWARE DIRECT
Model :MS355-48X2
Packaged Quantity :1
Product Line :Cisco Meraki Cloud Managed
Product Series :MS355
Interface Provided
Total Port :48 Port Network Switch
Comments :Stacking
Connector Type :QSFP28
Type :100Gbit LAN
Comments :Uplink
Connector Type & Qty :4 SFP+
Type :10Gbit LAN
Comments :UPOE
Connector Type :RJ-45
Qty :24
Type :100/1000/2.5G/5G/10GBase-T
Connector Type :QSFP+
Qty :2
Type :40Gbit LAN
Type :1000Base-T
Miscellaneous
Authentication Method :RADIUS
Color Category :Silver
Compliant Standards :C-Tick, CSA, IC, RoHS
Height (Rack Units) :1
MTBF :330,228 hours
Rack Mounting Kit :Included
Networking
Advanced Switching :Layer 3
Compliant Standards :IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at
Features :ARP support, Auto-negotiation, Bridge protocol data unit (BPDU), Broadcast Storm Control, Crossover detection, DHCP relay, DHCP server, Dynamic ARP Inspection (DAI), E-mail alert, Flow control, LLDP support, Loop Guard, Port mirroring, Push notification, Rapid Spanning Tree Protocol (RSTP) support, Role-Based Access Control (RBAC), Root Guard, SMS alert, Spanning Tree Protocol (STP) support, Static routing, Syslog support, Uni-Directional Link Detection (UDLD), VLAN support
Form Factor :Desktop, Rack-mountable
Jumbo Frame Support :9600 bytes
MAC Address Table Size :32K entries
Manageable :Yes
Max Units In A Stack :8
Ports Qty :48
Power Over Ethernet (PoE) :UPOE
Remote Management Protocol :SNMP
Routing Protocol :IGMP, OSPFv2, Static IP routing, VRRP
Stackable :Stackable
Subcategory :Network hubs and switches
Subtype :Gigabit Ethernet
Type :Switch
Power Device
Frequency Required :50/60 Hz
Hot-Plug :Hot-plug
Nominal Voltage :AC 120/230 V
Power Consumption Operational :1793 Watt
Power Provided :740 Watt
Type :Internal power supply
