Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks MX-series
Model :MX240
Packaged Quantity :1
Chassis
Supported Devices / Modules Qty :4
Modem
Type :None
Performance
Performance :Forwarding performance (large packets): 440 Mpps, Throughput: 120 Gbps, Switching capacity: 480 Gbps, Forwarding performance (large packets): 440 Mbps
Networking
Type :Router
Form Factor :Rack-mountable
Modular :Modular
Connectivity Technology :Wired
Routing Protocol :BGP, GRE
Remote Management Protocol :SNMP 3, SNMP 2, HTTP
Status Indicators :Status
Key Features :VPN support
Features :Modular design, Quality of Service (QoS), Layer 2 switching, Manageable, VPN support, High Availability, MPLS support, MPLS Fast Reroute (FRR), Layer 3 switching, Midplane
Expansion Slots
Expansion Slots :4 expansion slot
Power Device
Type :Internal power supply
Power Redundancy :Yes
Installed Qty :1
Max Supported Qty :2
Nominal Voltage :AC 120/230 V
Power Consumption Operational :1743 watt
Miscellaneous
Height (Rack Units) :5
Compliant Standards :EN 61000-4-6, EN 61000-4-3, RoHS, UL 1950 Third Edition, CSA C22.2 No. 60950-00, EN 61000-3-2, EN 61000-4-5, EN 61000-4-2, ETSI, EMC, EN 60825-1, EN55022 Class A, FCC Part 15 A, EN 61000-3-3, VCCI Class A ITE, EN 61000-4-4, NEBS, EN 61000-4-11, AS/NZS 3548 Class A, EN 60950, EN 55022 Class A
Dimensions & Weight
Width :17.5 inch
Depth :8.7 inch
Height :23.8 inch
Weight :130.07 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :5 – 90% (non-condensing)
