Interface Provided
Connector Type : QSFP+ (breakout compatible)
Qty : 56
Type : 40Gbit LAN
Connector Type : QSFP28
Qty : 8
Type : 100Gbit LAN
Connector Type : RJ-45
Qty : 3
Type : Management
Qty : 1
Type : USB
Type : Serial (RS-232)
Networking
Advanced Switching : Layer 3
Features : Access Control List (ACL) support, Hot Standby Router Protocol (HSRP) support, IGMP snooping, Multiple Spanning Tree Protocol (MSTP) support, Per-VLAN Rapid Spanning Tree (PVRST), Port exhaust, Virtual Routing and Forwarding (VRF), VLAN support, VXLAN tunnel endpoints (VTEP) support
Form Factor : Desktop, Rack-mountable
MAC Address Table Size : 96K entries
Manageable : Yes
Ports Qty : 56
Routing Protocol : BGP, ECMP, EIGRP, HSRP, MSDP, OSPF, PIM-SM, PIM-SSM, RIP-2
Subcategory : Network hubs and switches
Subtype : 40 Gigabit Ethernet
Type : Switch
Miscellaneous
Color Category : Gray
Compliant Standards : AS/NZS 60950-1, AS/NZS CISPR22:2004 Class A, CISPR 24, CNS 13438(95) Class A, CSA C22.2 No. 60950-1 Second Edition, EMC, EN 300386, EN 60950-1 Second Edition, EN55024, EN61000-3-2, EN61000-3-3, FCC CFR47 Part 15, GB 4943, ICES-003 Class A, IEC 60950-1 Second Edition, KN22 Class A, RoHS 6/6, UL 60950-1 Second Edition, VCCI Class A
Height (Rack Units) : 2
Included Accessories : Accessory kit, Rack mount kit
Rack Mounting Kit : Included
Environmental Parameters
Humidity Range Operating : 5 – 95% (non-condensing)
Max Operating Temperature : 104 °F
Max Storage Temperature : 158 °F
Min Operating Temperature : 32 °F
Min Storage Temperature : -40 °F
Header
Brand : Cisco
Compatibility : PC
Manufacturer : CISCO DS HARDWARE DIRECT
Model : 92304QC
Packaged Quantity : 1
Product Line : Cisco Nexus
Product Series: N9K
Power Device
Frequency Required : 50/60 Hz
Hot-Plug : Hot-plug
Installed Qty : 2
Max Supported Qty : 2
Nominal Voltage : AC 120/230 V
Power Provided : 650 Watt
Power Redundancy : Yes
Type : Internal power supply
Software
Type : Cisco NX-OS
Dimensions & Weight
Depth : 22.5 in
Height : 3.5 in
Weight : 33.02 lbs
Width : 17.5 in
Capacity
Type : ACL entries (egress)
Value : 2000
Type : ACL entries (ingress)
Value : 4000
Type : Equal-Cost Multipathing (ECMP) ways
Value : 64
Type : HSRP groups
Value : 490
Type : IGMP snooping entries
Value : 32000
Type : Longest prefix match (LPM) entries (IPv4)
Value : 16000
Type : MAC addresses
Value : 96000
Type : Multiple Spanning Tree Protocol instances
Type : Rapid Per-VLAN Spanning Tree Plus instances
Value : 507
Type : Virtual interfaces (VLANs)
Value : 4096
Type : Virtual Routing and Forwarding (VRF) entries
Performance
Type : Bandwidth
Value : 6.08 Tbps
Ports
Qty : 56
Type : 40 Gigabit QSFP+ (breakout compatible)
Ports (2nd)
Qty : 8
Type : 100 Gigabit QSFP28
RAM
Installed Size : 16 GB
