Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks QFX Series
Model :QFX5100-48S
Packaged Quantity :1
Chassis
Airflow Direction :Front to back airflow
Built-in Devices :32 GB SSD
Processor
Installed Qty :1
Manufacturer :Intel
Clock Speed :1.5 GHZ
RAM
Installed Size :8 GB
Performance
Performance :Switching capacity: 1.44 Tbps, Switching capacity: 1.07 Bpps
Capacity
Capacity :IPv4 hosts: 208000, IPv4 routes (Multicast): 104000, VLAN Spanning Tree Protocol instances: 253, IPv6 routes (Unicast): 64000, ARP entries: 48000, IPv6 routes (Multicast): 52000, Virtual interfaces (VLANs): 4091, IPv4 routes (Unicast): 128000, Multiple Spanning Tree Protocol instances: 64
Networking
Type :Switch
Subcategory :Network hubs and switches
Subtype :10 Gigabit Ethernet
Form Factor :Rack-mountable
Ports Qty :48
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Min Storage Temperature :-40 degree Fahrenheit
Max Storage Temperature :158 degree Fahrenheit
Humidity Range Operating :5 – 90% (non-condensing)
Humidity Range Storage :0 – 95% (non-condensing)
