Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks QFX Series
Model :QFX5110-48S
Packaged Quantity :1
Chassis
Airflow Direction :Back to front airflow
Performance
Performance :Switching capacity: 1.76 Tbps, Switching capacity: 1.32 Bpps
Capacity
Capacity :MAC address entries: 288000, Firewall ingress filters: 6142, QoS hardware queues per port: 12, IPv6 routes (Multicast): 52000, MSTP instances: 64, ARP entries: 48000, LAG groups: 104, IPv4 routes (Unicast): 128000, IPv6 routes (Unicast): 84000, VSTP instances: 253, Jumbo frame size: 9216, Firewall egress filters: 1022, IPv4 routes (Multicast): 104000, Maximum member ports per LAG: 32, VLAN IDs: 4093
Networking
Type :Switch
Subcategory :Network hubs and switches
Subtype :10 Gigabit Ethernet
Form Factor :Rack-mountable
Ports Qty :48
Advanced Switching :Layer 3
Routing Protocol :IGMPv3, RIP, IS-IS, VRRP, IGMP, Static IP routing, IGMPv2, OSPF, BGP
MAC Address Table Size :288K entries
Jumbo Frame Support :9216 bytes
Manageable :Yes
Remote Management Protocol :SNMP 2, SNMP 3, SNMP 1, CLI, TFTP, Telnet
Features :Store and forward, Priority-Based Flow Control (PFC), Rapid Spanning Tree Protocol (RSTP) support, Dynamic ARP Inspection (DAI), Virtual Extensible LAN (VXLAN), Storm Control, MPLS support, Data Center Bridging (DCB), Bridge protocol data unit (BPDU), Data Center Bridging Exchange (DCBX) support, Redundant fans, Bidirectional Forwarding Detection (BFD), DHCP relay, IP source guard, Multicast Source Discovery Protocol (MSDP), Spanning Tree Protocol (STP) support, DHCP snooping, Quality of Service (QoS), Back to front airflow, Weighted Random Early Detection (WRED), Smoothed Deficit Weighted Round Robin (SDWRR), sFlow v5, VLAN filtering, Private VLAN, Uplink Failure Detection (UFD), Routed VLAN Interface (RVI), VLAN support, Hot swappable fan, PIM-SM snooping, Multiple Spanning Tree Protocol (MSTP) support, IGMP filtering, Redundant trunk group (RTG), FCoE support, Port filtering, IGMP snooping, Port mirroring, High Availability, Proxy ARP, VLAN Spanning Tree Protocol (VSTP), Cut-through, Loop prevention, Management Information Base (MIB)
Compliant Standards :IEEE 802.3x, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP), IEEE 802.1Qbb, IEEE 802.1D, IEEE 802.11, IEEE 802.1s, IEEE 802.1p, IEEE 802.1Qaz, IEEE 802.1w, IEEE 802.1ad
Ports
Qty :48
Type :1 Gigabit / 10 Gigabit SFP+
Ports (2nd)
Qty :4
Type :40 Gigabit / 100 Gigabit QSFP28
Interface Provided
Interfaces :48 x 1/10Gbit LAN SFP+, 1 x serial (RS-232), 2 x management, 1 x USB 2.0, 4 x 100Gbit/40Gbit LAN QSFP28/QSFP+
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Power Redundancy :Yes
Power Redundancy Scheme :1+1
Installed Qty :2
Max Supported Qty :2
Nominal Voltage :AC 110/240 V
Power Consumption Operational :300 watt
80 PLUS Certification :80 PLUS Silver
Miscellaneous
Color Category :Gray
Rack Mounting Kit :Included
Height (Rack Units) :1
Authentication Method :TACACS+, RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2)
Compliant Standards :GR-63-CORE, EN 300 386, EN55024, CAN/CSA-C22.2 No. 60950-1, VCCI Class A, RoHS, EN 55022 Class A, UL 60950-1, CISPR 32 Class A, REACH, EN 55032 Class A, GR-1089-CORE, CISPR 24, CISPR 22 Class A, China RoHS, BSMI CNS 13438, EN 60825-1, ICES-003 Class A, IEC 60950-1, AS/NZS CISPR 22, WEEE, FCC CFR47 Part 15 A, AS/NZS CISPR32, AS/NZS CISPR 32
Dimensions & Weight
Width :17.4 inch
Depth :20.5 inch
Height :1.7 inch
Weight :22.99 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Min Storage Temperature :-40 degree Fahrenheit
Max Storage Temperature :158 degree Fahrenheit
Humidity Range Operating :5 – 90% (non-condensing)
Humidity Range Storage :0 – 95% (non-condensing)
