CPU
Chipset Intel Z490
CPU Socket LGA 1200
Back Panel I/O
USB 1 x USB 3.1 / USB 3.2 Gen 2 Type-C
3 x USB 3.1 / USB 3.2 Gen 2 Type-A
2 x USB 3.1 / USB 3.2 Gen 1 Type-A
2 x USB 2.0 Type-A
Display 1 x HDMI 2.0a
1 x DisplayPort 1.4
Ethernet / Controller 1 x Intel I225V 2.5Gigabit
Memory
Memory Slots 2 x 288-Pin
Memory Support DDR4 4800 MHz
Maximum Capacity 64 GB
Storage Expansion
SATA 6 x SATA III
M.2 2 x M Key 2242, 2260, 2280, 22110 (PCIe 3.0 x4, SATA III)
U.2 None
Internal I/O
Expansion Slots 1 x PCIe 3.0 x16
USB 2 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 4 USB Type-A Port)
2 x USB 2.0 Header (Supports 4 USB Type-A Port)
Multi-GPU Support None
LED Header 1 x RGB
Front Panel I/O
I/O Connection Headers USB 3.1 / USB 3.2 Gen 2
Audio
Audio Codec SupremeFX S1220A (8-Channel)
Wireless
Bluetooth 5.1
Wi-Fi Wi-Fi 6 (802.11ax)
Physical
Form Factor Mini-ITX
