Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS
Model :3000 LCD
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :RS-232, USB
Expansion Slots
Expansion Slots :1 SmartSlot
Interface Provided
Interfaces :1 x management (USB), 1 x management (RS-232)
Cable Details
Cables Included :USB cable – external, Serial cable – external, Power cable – integrated – 8 ft
Software
Type :Drivers & Utilities
Power Device
Form Factor :Rack-mountable
UPS Technology :Line interactive
Voltage Provided :208V
UPS Output Waveform :Sinewave
Power Provided :2.7 kilograms per millimetere
Power Capacity (VA) :3000 volt ampere per kilogram 3000VA
Voltage Required :AC 208 volt
Input Voltage Range :AC 141 – 255 V
Input Voltage Range (Adjustable) :AC 131 – 268 V
Frequency Required :50/60 hertz
Input Connector Type :Power NEMA L6-20
Input Connector Qty :1
Output Connector Qty :2
Surge Suppression :Yes
Surge Energy Rating :320 joules
Power Device Features :Audible alarm, LCD display, Automatic Voltage Regulation (AVR), LED indicators
Power Output Connectors Details
Power Output Connectors Details :2 x power NEMA L6-20
Battery
Run Time (Up To) :3.4 minute (time unit)
Load Type :At full load
Recharge Time :3 Hours
Run Time Details
Run Time (Up To) :3.4 min at full load, 11.7 min at half load
UPS
Batteries Qty :1
Battery Technology :Lead acid
Miscellaneous
Rack Mounting Kit :Included
Height (Rack Units) :2
Compliant Standards :FCC Part 15 A, REACH, UL 1778, CSA, RoHS Exemption 7b
Dimensions & Weight
Width :18.9 inch
Depth :27.2 inch
Height :3.4 inch
Weight :97.66 lbs
Dimensions & Weight (Shipping)
Shipping Width :23.6 inch
Shipping Depth :38.6 inch
Shipping Height :10 inch
Shipping Weight :113.98 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95%
Sound Emission :55 dBA
