Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS X
Model :SMX3000RMLVUS
Country Kits :Canada, United States
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :USB, RS-232
Expansion Slots
Expansion Slots :1 (total) / 1 (free) x SmartSlot
Interface Provided
Interfaces :1 x management (RS-232) – RJ-45, 1 x EPO (emergency power off), 1 x management (USB) – 4 pin USB Type B
Cable Details
Cables Included :Power cable – integrated – 8 ft, Serial cable – external
Software
Type :APC PowerChute Business Edition
Power Device
Form Factor :Rack-mountable / external
UPS Technology :Line interactive
Voltage Provided :AC 120 volt
Voltage Provided Margin :± 5%
Frequency Provided :50/60 hertz
Frequency Provided Margin :± 3Hz
UPS Output Waveform :Sinewave
Power Provided :2.7 kilograms per millimetere
Power Capacity (VA) :2880 volt ampere per kilogram 3000VA
Voltage Required :AC 120 volt
Input Voltage Range :AC 70 – 153 V
Frequency Required :50/60 hertz
Frequency Required Margin :± 3Hz
Input Connector Type :Power NEMA L5-30P
Input Connector Qty :1
Output Connector Type :3 x power NEMA 5-20R, Power NEMA L5-30R, 3 x power NEMA 5-15R
Output Connector Qty :7
Surge Suppression :Yes
Switchover Time :2 millisecond
Surge Energy Rating :540 joules
Efficiency :98.1% at 50% Load, 97.2% at 25% Load, 98.1% at 75% Load, 98% at 100% Load
Power Device Features :Green Function, Overload protection, Automatic Voltage Regulation (AVR), Hot-swappable batteries, Noise filtering, Intelligent Battery Management, LED indicators, Automatic self-test, Remote Emergency Power Off (REPO), Predicitive failure notification, Cold-start function, LCD display, Audible alarm, Temperature-compensated battery charging, Auto restart, Energy meter
Power Output Connectors Details
Power Output Connectors Details :3 x power NEMA 5-15R, 1 x power NEMA L5-30R, 3 x power NEMA 5-20R
Battery
Run Time (Up To) :6.3 minute (time unit)
Load Type :At full load
Recharge Time :3 Hours
Lead Acid Battery Features :Maintenance free, Sealed, Leak-proof
Run Time Details
Run Time (Up To) :6.3 min at full load, 18.1 min at half load
UPS
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Included Accessories :Removable support feet, Temperature probe
TAA Compliant :Yes
Rack Mounting Kit :Included
Height (Rack Units) :2
Equipment Protection Value :150000 US Dollars
Compliant Standards :UL 1778, REACH SvHC, EN 1499, EN 55022 Class A, FCC Part 15 A, RoHS, CSA, TUV, cUL, BSMI, NOM, Plug and Play
Environmental Standards
ENERGY STAR :Yes
Dimensions & Weight
Width :17 inch
Depth :26.3 inch
Height :3.3 inch
Weight :84.77 lbs
Dimensions & Weight (Shipping)
Shipping Width :23.5 inch
Shipping Depth :34.2 inch
Shipping Height :9.6 inch
Shipping Weight :100 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95%
Sound Emission :55 dBA
