Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS SRT
Model :3000VA RM
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :RS-232, USB
Expansion Slots
Expansion Slots :1 (total) / 1 (free) x SmartSlot
Interface Provided
Interfaces :1 x EPO (emergency power off), 1 x management (RS-232) – RJ-45, 1 x management (USB) – 4 pin USB Type A
Cable Details
Cables Included :USB cable – external, Power cable – external – 8 ft
Software
Type :Drivers & Utilities
Power Device
Form Factor :Rack-mountable
UPS Technology :On-line
Voltage Provided :AC 120 volt
Voltage Provided Margin :± 2%
Frequency Provided :50/60 hertz
Frequency Provided Margin :± 3Hz
UPS Output Waveform :Sinewave
Power Provided :2700 watt
Power Capacity (VA) :3000 volt ampere per kilogram 3000VA
Voltage Required :AC 120 volt
Frequency Required :40 – 70 hertz
Input Connector Type :Power NEMA L5-30P
Input Connector Qty :1
Output Connector Type :Power NEMA 5-20R, Power NEMA L5-30
Output Connector Qty :9
Surge Suppression :Yes
Surge Energy Rating :340 joules
Efficiency :91.9% at 75% Load, 91.7% at 50% Load, 91.6% at 100% Load, 89.4% at 25% Load
Power Device Features :Internal bypass, LCD display, Eco-Mode, Audible alarm
Power Output Connectors Details
Power Output Connectors Details :1 x power NEMA L5-30, 8 x power NEMA 5-20R
Battery
Technology :Lead acid
Run Time (Up To) :3.2 minute (time unit)
Load Type :At full load
Recharge Time :3 Hours
Lead Acid Battery Features :Maintenance free, Leak-proof, Sealed
Run Time Details
Run Time (Up To) :3.2 min at full load
Miscellaneous
Color :Black
Color Category :Black
Rack Mounting Kit :Included
Height (Rack Units) :2
Compliant Standards :IP20, IEC 62040-1, RoHS, IEC 62040-2, EAC, VDE, RCM, EN 62040-2, EN 62040-1
Environmental Standards
ENERGY STAR :Yes
Dimensions & Weight
Width :17 inch
Depth :25 inch
Height :3.3 inch
Weight :69 lbs
Dimensions & Weight (Shipping)
Shipping Width :23.6 inch
Shipping Depth :34.3 inch
Shipping Height :9.7 inch
Shipping Weight :88.01 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95% (non-condensing)
Sound Emission :55 dBA
