Manufacturer :APC
Brand :APC
Product Line :APC Marine Smart-UPS On-Line
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :Serial, Ethernet
Expansion Slots
Expansion Slots :1 SmartSlot
Interface Provided
Interfaces :1 x management (Ethernet) – RJ-45, 1 x sensor – RJ-45, 1 x serial – RJ-45, 1 x EPO (emergency power off), 1 x USB – 4 pin USB Type B
Power Device
Form Factor :Rack-mountable / external
UPS Technology :On-line
Voltage Provided :AC 220/230/240 volt
Frequency Provided :50/60 hertz
Frequency Provided Margin :± 3Hz
Power Provided :4500 watt
Power Capacity (VA) :5000 volt ampere per kilogram
Voltage Required :AC 220/230/240 volt
Input Voltage Range :AC 100 – 275 V
Frequency Required :40 – 70 hertz
Input Connector Type :Hardwire 3-wire (1PH + N + G)
Input Connector Qty :1
Output Connector Type :4 x power IEC 60320 C19, 6 x power IEC 60320 C13
Output Connector Qty :10
Power Device Features :LED display, Emergency power off
Power Output Connectors Details
Power Output Connectors Details :6 x power IEC 60320 C13, 4 x power IEC 60320 C19
Battery
Run Time (Up To) :4 minute (time unit)
Load Type :At full load
Recharge Time :1.5 Hours
Lead Acid Battery Features :Leak-proof, Sealed, Maintenance free
Run Time Details
Run Time (Up To) :4 min at full load, 12 min at half load
UPS
Battery Technology :Lead acid
Miscellaneous
Color Category :Black
Height (Rack Units) :3
Compliant Standards :KCC, EAC, IEC 62430, VFI-SS-111, IEC 62040-3, IEC 60945, RCM, IEC 62040-2, IEC 62040-1, IACS-E10, VDE, IEC 62040-4
Dimensions & Weight
Width :17 inch
Depth :28.3 inch
Height :5.1 inch
Weight :121.25 lbs
