Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks
Model :SRX320 Services Gateway
Packaged Quantity :1
Chassis
Airflow Direction :Front to back airflow
RAM
Installed Size :4 GB
Flash Memory
Installed Size :8 GB, 8 GB
Performance
Performance :Firewall throughput (1518-byte packet size): 1 Gbps, Connection rate: 5000 connections per second, VPN throughput (IPSec): 100 Mbps, VPN throughput (1400-byte packet size): 300 Mbps, Firewall throughput (64-byte packet size): 200 Kpps, IPS throughput: 200 Mbps, Firewall throughput (IMIX): 500 Mbps
Capacity
Capacity :Virtual interfaces (VLANs): 1000, MAC addresses: 15000, Concurrent sessions: 64000, Virtual routers: 32, Maximum number of remote users: 50, Security policies: 1000, Maximum number of NAT rules: 1000, Security zones: 16, IPv6 routing table entries: 256000, IPSec VPN tunnels: 256, IPv4 routing table entries: 256000, GRE tunnels: 256
Networking
Type :Security appliance
Form Factor :Desktop
Ports Qty :8
Connectivity Technology :Wired
Data Link Protocol :MLPPP, HDLC, PPP, Gigabit Ethernet, Fast Ethernet, Ethernet, MLFR, Frame Relay
Routing Protocol :IGMPv2, DVMRP, IGMP, PIM-SM, ECMP, PIM-DM, MSDP, PIM-SSM, IS-IS, RIP-2, RIP-1, Static IP routing, MPLS, BGP, OSPF, OSPFv3, VRRP
Network / Transport Protocol :PPPoE, DNS, DHCP, RSVP, DDNS, IPSec
Remote Management Protocol :SSH, SNMP, CLI, HTTP, Telnet
Features :VPN support, URL filtering, Anti-virus protection, Anti-spam protection, Generic Routing Encapsulation (GRE), DiffServ Code Point (DSCP) support, DHCP server, Quality of Service (QoS), Weighted Random Early Detection (WRED), IPSec NAT-Traversal (NAT-T), LLDP support, DHCP relay, Label Distribution Protocol (LDP), Firewall protection, J-Flow, IPv4 support, Intrusion Prevention System (IPS), Virtual Private LAN Service (VPLS), DHCP client, Dead Peer Detection (DPD), Front to back airflow, Rapid Spanning Tree Protocol (RSTP) support, NAT support, DDos attack prevention, Inspect SSL Encrypted Traffic, Spanning Tree Protocol (STP) support, MACsec support, IPv6 support, PAT support
Compliant Standards :IEEE 802.1x, IEEE 802.1p
IP Telephony
VoIP Protocols :SDP
Expansion Slots
Expansion Slots :2 (total) / 2 (free) x expansion slot
Interface Provided
Interfaces :6 x 1000Base-T – RJ-45, 1 x mini-USB, 1 x USB 3.0 – Type A, 2 x 1000Base-X – SFP (mini-GBIC), 1 x console – RJ-45
OS Provided
Type :JUNOS
Software
Type :Junos Software Enhanced
Power Device
Type :External power adapter
Power Consumption Operational :27 watt
Miscellaneous
Color Category :Gray
TAA Compliant :Yes
Encryption Algorithm :MD5, PKI, 256-bit SHA, IKEv2, 256-bit AES, SHA-1, DES, IKE, SSL, Triple DES
Authentication Method :X.509 certificates, Secure Shell (SSH)
Compliant Standards :RoHS2, FCC Class A certified
Dimensions & Weight
Width :11.8 inch
Depth :7.5 inch
Height :1.7 inch
Weight :3.33 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :10 – 90% (non-condensing)
