Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks
Model :SRX340 Services Gateway
Packaged Quantity :1
Chassis
Airflow Direction :Front to back airflow
RAM
Installed Size :4 GB
Flash Memory
Installed Size :8 GB, 8 GB
Hard Drive
Type :SSD
Performance
Performance :Firewall throughput (64-byte packet size): 350 Kpps, Firewall throughput (1518-byte packet size): 3 Gbps, VPN throughput (1400-byte packet size): 500 Mbps, Connection rate: 10000 connections per second, Firewall throughput (IMIX): 1 Gbps, VPN throughput (IPSec): 150 Mbps, IPS throughput: 250 Mbps
Capacity
Capacity :GRE tunnels: 512, IPv4 routing table entries: 1000000, Virtual routers: 64, Security policies: 2000, Maximum number of users: 100, MAC addresses: 15000, Concurrent sessions: 256000, Virtual interfaces (VLANs): 2000, IPSec VPN tunnels: 1024, Maximum number of NAT rules: 2000, Security zones: 64, IPv6 routing table entries: 600000
Networking
Type :Security appliance
Form Factor :Rack-mountable
Ports Qty :16
Connectivity Technology :Wired
Data Link Protocol :Frame Relay, HDLC, MLFR, PPP, Fast Ethernet, Ethernet, Gigabit Ethernet, MLPPP
Routing Protocol :VRRP, MPLS, IGMPv2, OSPF, PIM-SSM, BGP, PIM-DM, IS-IS, RIP-1, ECMP, RIP-2, IGMP, Static IP routing, DVMRP, MSDP, OSPFv3, PIM-SM
Network / Transport Protocol :DDNS, DHCP, RSVP, DNS, IPSec, PPPoE
Remote Management Protocol :SNMP, CLI, Telnet, HTTP, SSH
Features :Quality of Service (QoS), Generic Routing Encapsulation (GRE), DHCP client, IPv6 support, PAT support, Front to back airflow, Anti-spam protection, J-Flow, URL filtering, DiffServ Code Point (DSCP) support, Spanning Tree Protocol (STP) support, Anti-virus protection, MACsec support, NAT support, IPv4 support, Intrusion Prevention System (IPS), DDos attack prevention, Weighted Random Early Detection (WRED), Label Distribution Protocol (LDP), Virtual Private LAN Service (VPLS), LLDP support, DHCP relay, VPN support, IPSec NAT-Traversal (NAT-T), Rapid Spanning Tree Protocol (RSTP) support, Inspect SSL Encrypted Traffic, Firewall protection, DHCP server, Dead Peer Detection (DPD)
Compliant Standards :IEEE 802.1x, IEEE 802.1p
IP Telephony
VoIP Protocols :SDP
Expansion Slots
Expansion Slots :4 (total) / 4 (free) x expansion slot
Interface Provided
Interfaces :8 x 1000Base-T – RJ-45, 1 x management – RJ-45, 1 x console – RJ-45, 1 x mini-USB, 8 x 1000Base-X – SFP (mini-GBIC), 1 x USB 2.0 – Type A
OS Provided
Type :JUNOS
Power Device
Type :Internal power supply
Power Consumption Operational :122 watt
Miscellaneous
TAA Compliant :Yes
Height (Rack Units) :1
Encryption Algorithm :MD5, 256-bit AES, 256-bit SHA, IKE, IKEv2, SHA-1, PKI, DES, SSL, Triple DES
Authentication Method :Secure Shell (SSH), X.509 certificates
Compliant Standards :RoHS2, FCC Class A certified
Dimensions & Weight
Width :17.4 inch
Depth :14.6 inch
Height :1.7 inch
Weight :10.8 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :10 – 90% (non-condensing)
