Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks
Model :SRX4200 Services Gateways
Packaged Quantity :1
Chassis
Airflow Direction :Front to back airflow
RAM
Installed Size :64 GB
Hard Drive
Type :SSD
Installed Qty :2
Capacity :240 GB
Performance
Performance :Application control (AVC) throughput: 35 Gbps, Connection rate: 350000 connections per second, NGFW throughput: 15 Gbps, IPSes throughput (1400-byte packet size): 20 Gbps, Intrusion prevention throughput: 20 Gbps, Firewall throughput (64-byte packet size): 10 Gbps, Firewall throughput (IMIX): 40 Gbps, Firewall throughput (1518-byte packet size): 80 Gbps, VPN throughput (IPSec): 9.6 Gbps
Capacity
Capacity :Forwarding table entries: 2000000, Maximum number of concurrent sessions: 10000000, Routing table entries: 2000000, Security policies: 60000
Networking
Type :Security appliance
Form Factor :Rack-mountable
Ports Qty :8
Connectivity Technology :Wired
Data Link Protocol :Gigabit Ethernet, 10 Gigabit Ethernet
Routing Protocol :IS-IS, BGP, Static IPv6 routing, RIP-1, OSPFv3, OSPF, RIP-2, IGMPv2, IGMP, Static IPv4 routing, Bidirectional PIM
Network / Transport Protocol :PPPoE, DHCP, IPSec
Remote Management Protocol :SSH, Telnet, SNMP
Features :DiffServ Code Point (DSCP) support, Virtual Private LAN Service (VPLS), DNS proxy, Anti-spam protection, DHCP server, VLAN support, DHCP relay, Dead Peer Detection (DPD), Dynamic DNS server, IGMP filtering, NAT support, DHCP client, VPN support, Antivirus analysis, IPSec Virtual Private Network (VPN), Equal-Cost Multipath (ECMP), DDos attack prevention, Quality of Service (QoS), Intrusion Prevention System (IPS), MPLS support, Weighted Random Early Detection (WRED), IPv6 support, Virtual Route Redundancy Protocol (VRRP) support, Multicast Source Discovery Protocol (MSDP), IPSec NAT-Traversal (NAT-T), Generic Routing Encapsulation (GRE), Firewall protection, Source-Specific Multicast (SSM), J-Flow, Label Distribution Protocol (LDP), High Availability, Front to back airflow
Compliant Standards :X.509, IEEE 802.1p
Interface Provided
Interfaces :1 x 1000Base-T (management) – RJ-45, 2 x USB 2.0 – Type A, 8 x 10Gb Ethernet – SFP+, 2 x 10Gb Ethernet – SFP+, 1 x console – RJ-45
OS Provided
Type :JUNOS
Software
Type :Junos Software Enhanced
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Power Redundancy :Yes
Installed Qty :2
Power Provided :650 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Power Consumption Operational :200 watt
Miscellaneous
Color Category :Gray
Height (Rack Units) :1
Encryption Algorithm :256-bit SHA, 256-bit AES, 128-bit SHA, SHA-1, IKE, PKI, Triple DES, IKEv2
MTBF :12 years
Compliant Standards :FCC Class A certified, RoHS2
Dimensions & Weight
Width :17.5 inch
Depth :25 inch
Height :1.7 inch
Weight :28.99 lbs
Dimensions & Weight (Shipping)
Shipping Weight :47.49 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :5 – 90% (non-condensing)
