Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks
Model :SRX 5400
Bundled with :Juniper Networks SRX5K-RE-1800X4, SRX5K-SCB3, SRX5K-SPC-4-15-320, SRX5K-MPC3-40G10G
Packaged Quantity :1
Chassis
Built-in Devices :Enhanced midplane
Performance
Performance :IPS throughput: 22 Gbps, Firewall throughput: 65 Gbps, VPN throughput (256-bit AES+SHA1 IPSec): 35 Gbps, Firewall throughput (IMIX): 468 Gbps, Firewall throughput (large packets): 480 Gbps, Latency: 7 µs
Capacity
Capacity :OSPF instances: 400, OSPF routes: 1000000, VPN tunnels (site-to-site): 15000, Maximum number of users: unlimited, BGP peers: 2000, Security zones: 2000, New sessions per second: 420000, Virtual interfaces (VLANs): 4096, BGP routes: 1000000, VPN tunnel interfaces: 15000, Virtual routers: 2000, Maximum logical network members: 32, RIP instances: 50, BGP instances: 1000, Concurrent sessions: 28000000
Networking
Type :Security appliance
Form Factor :Rack-mountable
Connectivity Technology :Wired
Routing Protocol :OSPFv3, OSPF, Bidirectional Forwarding Detection (BFD), RIPng, Static IP routing, Policy-based routing (PBR), RIP-2, IPv4-to-IPv6 Multicast, RIP-1, BGP, ECMP
Network / Transport Protocol :DHCP
Remote Management Protocol :HTTPS, Telnet, SNMP 3, CLI, SNMP 2, SSH, HTTP
Features :Firmware upgradable, DDos attack prevention, Quality of Service (QoS), VPN support, DHCP relay, Weighted Round Robin (WRR) queuing, Syslog support, High Availability, Intrusion Prevention System (IPS), Traffic Control, In-Service Software Upgrade (ISSU), Class of Service (CoS), Traffic shaping, PAT support, DiffServ support, Link Aggregation Control Protocol (LACP), NAT support, Firewall protection, Weighted Random Early Detection (WRED), Fan tray, DHCP server, IPSec Virtual Private Network (VPN), DoS attack prevention, Anti-spyware protection, IPv6 support, Anti-malware protection
Expansion Slots
Expansion Slots :1 (total) / 0 (free) x Switch Control Board (SCB), 2 (total) / 1 (free) x Service Processing Card (SPC), 2 (total) / 1 (free) x expansion slot, 1 (total) / 0 (free) x Routing Engine (RE)
Interface Provided
Interfaces :6 x 40Gb Ethernet – QSFP+, 24 x 10Gb Ethernet – SFP+
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Power Redundancy :Optional
Installed Qty :2
Max Supported Qty :4
Power Provided :4100 watt
Nominal Voltage :AC 120/230 V
System Requirements
OS Required :JUNOS
Miscellaneous
Encryption Algorithm :Triple DES, AES, SHA-1, MD5, DES, PKI, DH, IKE
Authentication Method :RADIUS
Compliant Standards :NEBS level 3, Common Criteria EAL4+, EMC
Dimensions & Weight
Width :17.4 inch
Depth :24.5 inch
Height :8.7 inch
Environmental Parameters
Min Operating Temperature :41 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :5 – 85% (non-condensing)
