Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks
Model :SRX 5400
Kit :Cluster Bundle
Bundled with :Juniper Networks 2x SRX5K-RE-1800X4, 2x SRX5K-SCB3, 2x SRX5K-SPC-4-15-320, 2x SRX5K-MPC, 2x SRX-MIC-10XG-SFPP, 4x SRX5600-PWR-2520-AC-S, 2x SRX5400-APPSEC-1
Packaged Quantity :2
Chassis
Built-in Devices :Enhanced midplane
Performance
Performance :Firewall throughput (IMIX): 468 Gbps, Latency: 7 µs, VPN throughput (256-bit AES+SHA1 IPSec): 35 Gbps, Firewall throughput (large packets): 480 Gbps, Firewall throughput: 65 Gbps, IPS throughput: 22 Gbps
Capacity
Capacity :Virtual interfaces (VLANs): 4096, Maximum number of users: unlimited, BGP peers: 2000, BGP instances: 1000, OSPF routes: 1000000, VPN tunnel interfaces: 15000, BGP routes: 1000000, Virtual routers: 2000, Concurrent sessions: 42000000, Security zones: 2000, Maximum logical network members: 32, RIP instances: 50, New sessions per second: 420000, OSPF instances: 400, VPN tunnels (site-to-site): 15000
Networking
Type :Security appliance
Form Factor :Rack-mountable
Connectivity Technology :Wired
Routing Protocol :BGP, Static IP routing, IPv4-to-IPv6 Multicast, OSPFv3, Bidirectional Forwarding Detection (BFD), Policy-based routing (PBR), OSPF, RIPng, RIP-1, RIP-2, ECMP
Network / Transport Protocol :DHCP
Remote Management Protocol :CLI, HTTPS, SNMP 2, SNMP 3, SSH, HTTP, Telnet
Features :Intrusion Prevention System (IPS), In-Service Software Upgrade (ISSU), DoS attack prevention, IPv4 support, High Availability, VPN support, Quality of Service (QoS), Link Aggregation Control Protocol (LACP), Firmware upgradable, Firewall protection, PAT support, Traffic Control, Fan tray, Anti-malware protection, Weighted Round Robin (WRR) queuing, IPSec Virtual Private Network (VPN), Weighted Random Early Detection (WRED), NAT support, DHCP relay, IPv6 support, DDos attack prevention, Syslog support, DHCP server, DiffServ support, Anti-spyware protection, Traffic shaping, Class of Service (CoS)
Expansion Slots
Expansion Slots :1 (total) / 0 (free) x Switch Control Board (SCB), 2 (total) / 1 (free) x Service Processing Card (SPC), 1 (total) / 0 (free) x Routing Engine (RE), 2 (total) / 1 (free) x expansion slot
Interface Provided
Interfaces :10 x 10Gb Ethernet – SFP+
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Power Redundancy :Optional
Installed Qty :2
Max Supported Qty :4
Power Provided :4100 watt
Nominal Voltage :AC 120/230 V
Power Consumption Operational :1540 watt
System Requirements
OS Required :JUNOS
Miscellaneous
Pricing Type :Promo
Encryption Algorithm :SHA-1, Triple DES, DH, AES, MD5, PKI, IKE, DES
Authentication Method :RADIUS, X.509 certificates
Compliant Standards :NEBS level 3, ICSA Firewall certified, ICSA IPSec certified, EMC, RoHS2
Dimensions & Weight
Width :17.4 inch
Depth :24.5 inch
Height :8.7 inch
Environmental Parameters
Min Operating Temperature :41 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :5 – 85% (non-condensing)
