Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks
Model :SRX550 Services Gateway
Packaged Quantity :1
RAM
Installed Size :4 GB
Flash Memory
Installed Size :8 GB, 8 GB
Performance
Performance :Antivirus throughput: 300 Mbps, Routing throughput: 1000000 packets per second, Firewall throughput (64-byte packet size): 700000 packets per second, Connection rate: 27000 connections per second, Firewall throughput (IMIX): 2 Gbps, Firewall throughput (large packets): 7 Gbps, IPS throughput: 800 Mbps, Firewall throughput (HTTP): 2 Gbps, VPN throughput (IPSec): 1 Gbps
Capacity
Capacity :BGP instances: 56, RIP instances: 56, Concurrent VPN tunnels: 2000, Concurrent sessions: 375000, RIP routes: 712000, Static routes: 100000, OSPF instances: 56, IPSec VPN tunnels: 2000, VPN tunnel interfaces: 456, BGP routes: 712000, OSPF routes: 200000, BGP peers: 192, Security zones: 96, MLPPP maximum physical interfaces: 12, MLFR maximum physical interfaces: 12, Maximum number of users: unlimited, Virtual routers: 128, RIP routes: 32000, Virtual interfaces (VLANs): 3967, Maximum number of remote users: 500, Security policies: 8000
Networking
Type :Security appliance
Form Factor :Rack-mountable
Connectivity Technology :Wired
Data Link Protocol :HDLC, Gigabit Ethernet, FRF.15, V.35, PPP, FRF.12, RS-449, MLFR, Ethernet, RS-232, FRF.16, Frame Relay, MLPPP, Fast Ethernet, X.21
Routing Protocol :GRE, OSPF, DVMRP, PIM-SSM, BGP, IGMP, IGMPv2, VRRP, RIPng, IS-IS, MSDP, PIM-DM, MLD, Static IP routing, RIP-1, RIP-2, MPLS, OSPFv3, PIM-SM, IGMPv3, ECMP
Switching Protocol :Ethernet, Frame Relay
Network / Transport Protocol :IPSec, RSVP, PPPoA, PPPoE, DHCP
Features :DiffServ support, Syslog support, 3G/4G USB Dongle Support, NAT support, IPv6 support, Quality of Service (QoS), DoS attack prevention, LLDP support, DDos attack prevention, Rapid Spanning Tree Protocol (RSTP) support, Link Fragmentation and Interleaving (LFI), PAT support, VPN support, DHCP server, Multiple Spanning Tree Protocol (MSTP) support, IPv4 support, IGMP snooping, Content filtering, Tagged VLAN, J-Flow, Weighted Random Early Detection (WRED), DiffServ Code Point (DSCP) support, DHCP relay, Firewall protection, Modular design
Compliant Standards :IEEE 802.3ad (LACP), IEEE 802.1p, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.1ad
Expansion Slots
Expansion Slots :8 (total) / 8 (free) x expansion slot
Interface Provided
Interfaces :6 x 1000Base-T – RJ-45, 2 x USB – Type A, 4 x 1000Base-X – SFP (mini-GBIC)
OS Provided
Type :JUNOS
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Power Redundancy :Optional
Installed Qty :1
Max Supported Qty :2
Power Provided :645 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Power Consumption Operational :85 watt
Miscellaneous
Included Accessories :Rack mount kit
TAA Compliant :Yes
Height (Rack Units) :2
Encryption Algorithm :DES, Triple DES, PKI, IKEv2, RSA, 256-bit SHA, SHA-1, DH, 128-bit AES, 256-bit SHA-2, 256-bit AES, MD5, IKE
Authentication Method :LDAP, RADIUS, XAUTH (RADIUS, LDAP, Active Directory), SecurID, X.509 certificates
MTBF :9.6 years
Compliant Standards :EN 60950-1, EN 300386, CB, AS/NZS 60950-1, DOC, ICES Class A, EN55022 Class A, CISPR 22 Class A, UL 60950-1, CS-03, ICSA Firewall certified, JITC, VCCI Class A, FCC Class A certified, ICSA IPSec certified, CSA C22.2 No. 60950-1
Dimensions & Weight
Width :17.5 inch
Depth :18.2 inch
Height :3.5 inch
Weight :21.96 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :10 – 90% (non-condensing)
