Header
Manufacturer
Highpoint
Brand
HighPoint
Product Line
HighPoint
Model
SSD7180
Packaged Quantity
1
General
Product Type
Storage controller (RAID)
Storage Controller
Form Factor
Plug-in card
Host Bus
PCIe 3.0 x16
Low Profile
Low profile
Data Transfer Rate
8 GBps
Interface
U.2 NVMe
Channel Qty
8
Supported Devices
Disk array (RAID), Solid state drive
Max Storage Devices Qty
8
RAID Level
JBOD, RAID 0, RAID 1, RAID 10
Interface Provided
Interfaces
8 x U.2 NVMe – Mini SAS HD (SFF-8643) (internal)
Interface Required
Connections
1 x PCIe 3.0 x16
Software
Type
Command Line Interface (CLI), Drivers & Utilities
Power Device
Type
None
System Requirements
OS Required
Apple macOS 10.13 or later, Linux Kernel 3.10 or later, Microsoft Windows Server 2016, Windows 10
Miscellaneous
Color Category
Silver
Hard Drive Form Factor Compatibility
2.5″
Hard Drive Form Factor Compatibility (metric)
6.4 cm
MTBF
920,585 Hours
Compliant Standards
FCC, REACH, RoHS, WEEE
Features
Alarm, Automatic disk rebuild, Built-in cooling fan, S.M.A.R.T. support, SMTP support, Storage Health Inspector, Supports NVM Express, TRIM support
Dimensions & Weight
Width
0.8 inch
Depth
6.5 inch
Height
2.7 inch
Weight
14.81 ounce
Environmental Parameters
Min Operating Temperature
41 degree Fahrenheit
Max Operating Temperature
131 degree Fahrenheit
