Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS
Bundled with :208V to 120/208V Transformer
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :RS-232, Ethernet 10/100
Remote Management Protocol :Telnet, SNMP, HTTP
Expansion Slots
Expansion Slots :1 (total) / 0 (free) x SmartSlot
Interface Provided
Interfaces :1 x management (RS-232) – 9 pin D-Sub (DB-9), 1 x management (Ethernet) – RJ-45
Cable Details
Cables Included :Power cable 8 ft, Serial cable – external
Software
Type :Drivers & Utilities
Power Device
Form Factor :External
UPS Technology :Line interactive
Voltage Provided :AC 120/208 volt
120V
Voltage Provided Margin :± 5%
Frequency Provided :50/60 hertz
UPS Output Waveform :Sinewave
Power Provided :4 kilograms per millimetere
Power Capacity (VA) :5000 volt ampere per kilogram 5000VA
Voltage Required :AC 208 volt
Input Voltage Range :AC 157 – 255 V
Input Voltage Range (Adjustable) :AC 151 – 268 V
Frequency Required :50/60 hertz
Input Connector Type :Power NEMA L6-30
Input Connector Qty :1
Output Connector Type :Power NEMA L6-20, Power NEMA 5-20, Power NEMA 5-15
Output Connector Qty :15
Surge Suppression :Yes
Surge Energy Rating :1020 joules
Power Device Features :Audible alarm, Noise filtering, LED indicators
Power Output Connectors Details
Power Output Connectors Details :1 x power NEMA L6-30, 2 x power NEMA L6-20, 12 x power NEMA 5-20
Battery
Run Time (Up To) :9.4 minute (time unit)
Load Type :At full load
Recharge Time :3 Hours
Run Time Details
Run Time (Up To) :9.4 min at full load
UPS
Batteries Qty :2
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Rack Mounting Kit :Included
Height (Rack Units) :7
Equipment Protection Value :150000 US Dollars
Compliant Standards :FCC Class A certified, CSA, UL 1449, UL 1778, FCC Part 15
Dimensions & Weight
Width :19 inch
Depth :25 inch
Height :12.2 inch
Weight :319.67 lbs
Dimensions & Weight (Shipping)
Shipping Width :24 inch
Shipping Depth :30 inch
Shipping Height :25 inch
Shipping Weight :354.94 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95%
Sound Emission :53 dBA
