Output
Max Configurable Power (Watts)
45.0kWatts / 50.0kVA
Efficiency at Full Load
93.3 %
Output Frequency (sync to mains)
60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal
Load Crest Factor
3 : 1
Overload Operation
10 minutes @ 125% and 30 seconds @ 150%
Output Voltage THD
< 1% linear load and < 2.5% nonlinear load Output Voltage Tolerance +/- 1% static and +/- 2 % at 100% load step Bypass Internal Bypass (Automatic and Manual), Optional External Bypass Input Input frequency 45 – 65 Hz, 60 Hz +/- 5 Hz Input voltage range for main operations 408 – 552 (480)V Efficiency at Full Load 93.3 % Input Total Harmonic Distortion Less than 5% for full load Type of Input Protection Required 3-pole breaker Maximum Short Circuit Withstand (Icw) 20.0kAmps Input Power Factor at Full Load 1.0 Batteries & Runtime Battery type VRLA Communications & Management Control panel Multi-function LCD status and control console Emergency Power Off (EPO) Optional Available SmartSlot™ Interface Quantity 3 Physical Maximum Height 75.0inches (1905MM, 190.5CM) Maximum Width 125.3inches (3183MM, 318.3CM) Maximum Depth 32.0inches (813MM, 81.3CM) Net Weight 4650.0lbs. (2113.64KG) Shipping weight 4720.0lbs. (2145.45KG) Shipping Height 76.0inches (1930MM, 193.0CM) Shipping Width 133.0inches (3378MM, 337.8CM) Shipping Depth 33.0inches (838MM, 83.8CM) Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 5 – 95 % Operating Elevation 0-3333ft (0-999.9meters) Storage Temperature -25 – 40 °C Storage Relative Humidity 0 – 95 % Storage Elevation 0-30000ft (0-9000meters) Audible noise at 1 meter from surface of unit 65.0dBA Online thermal dissipation 11021.0BTU/hr
