Output
Max Configurable Power (Watts)
72.0kWatts / 80.0kVA
Efficiency at Full Load
92.8 %
Output Voltage Distortion
Less than 2%
Output Frequency (sync to mains)
60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal
Load Crest Factor
3 : 1
Topology
Double Conversion Online
Overload Operation
10 minutes @ 125% and 60 seconds @ 150%
Output Voltage THD
< 1% linear load and < 2.5% nonlinear load Output Voltage Tolerance +/- 1% static and +/- 2 % at 100% load step Bypass Internal Bypass (Automatic and Manual), Optional External Bypass Input Input frequency 45 – 65 Hz, 60 Hz +/- 5 Hz Input voltage range for main operations 408 – 552 (480)V Efficiency at Full Load 92.8 % Input Total Harmonic Distortion Less than 3% for full load Type of Input Protection Required 3-pole breaker Maximum Short Circuit Withstand (Icw) 20.0kAmps Input Power Factor at Full Load 1.0 Batteries & Runtime Battery type No internal battery – uses external battery system Communications & Management Control panel Multi-function LCD status and control console Emergency Power Off (EPO) Optional Available SmartSlot™ Interface Quantity 3 Physical Maximum Height 75.0inches (1905MM, 190.5CM) Maximum Width 173.8inches (4415MM, 441.5CM) Maximum Depth 33.39inches (848MM, 84.8CM) Net Weight 15094.0lbs. (6860.91KG) Shipping weight 15194.0lbs. (6906.36KG) Shipping Height 79.92inches (2030MM, 203.0CM) Shipping Width 175.75inches (4464MM, 446.4CM) Shipping Depth 37.8inches (960MM, 96.0CM) Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 5 – 95 % Operating Elevation 0-3333ft (0-999.9meters) Storage Temperature -25 – 40 °C Storage Relative Humidity 0 – 95 % Storage Elevation 0-40000ft (0-12000meters) Audible noise at 1 meter from surface of unit 63.0dBA Online thermal dissipation 19791.0BTU/hr Protection Class IP 20
