Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS RT
Model :3000
Edition :Marine
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :RS-232
Expansion Slots
Expansion Slots :1 (total) / 1 (free) x SmartSlot
Interface Provided
Interfaces :1 x management (RS-232) – RJ-45
Cable Details
Cables Included :Power cable 8 ft, Serial cable – external
Software
Type :Drivers & Utilities
Power Device
Form Factor :External
UPS Technology :On-line
Voltage Provided :AC 220/230/240 volt
Voltage Provided Margin :± 3%
Frequency Provided :50/60 hertz
UPS Output Waveform :Sinewave
Power Provided :2.1 kilograms per millimetere
Power Capacity (VA) :3000 volt ampere per kilogram
Voltage Required :AC 220/230/240 volt
Input Voltage Range :AC 180 – 270 V
Input Voltage Range (Adjustable) :AC 100 – 280 V
Frequency Required :50/60 hertz
Input Connector Type :Power
Input Connector Qty :1
Output Connector Qty :10
Surge Suppression :Yes
Surge Energy Rating :480 joules
Power Device Features :LED indicators, Internal bypass
Power Output Connectors Details
Power Output Connectors Details :8 x power IEC 60320 C13, 2 x power IEC 60320 C19
Battery
Run Time (Up To) :14.1 minute (time unit)
Load Type :At full load
Recharge Time :2.5 Hours
Run Time Details
Run Time (Up To) :14.1 min at full load
UPS
Batteries Qty :1
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Height (Rack Units) :3
Compliant Standards :EN 50091-1, EN 50091-2, REACH, EN 61000-3-2, EN 60950, RoHS Exemption 7b, UL 1449, EN55022 Class A
Dimensions & Weight
Width :5.1 inch
Depth :26 inch
Height :17 inch
Weight :120.37 lbs
Dimensions & Weight (Shipping)
Shipping Width :23.7 inch
Shipping Depth :38.6 inch
Shipping Height :13.7 inch
Shipping Weight :140.21 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :131 degree Fahrenheit
Humidity Range Operating :0 – 95%
Sound Emission :55 dBA
