Output
Max Configurable Power (Watts)
500.0kWatts / 500.0kVA
Output Voltage Distortion
Less than 2%
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal, 50Hz +/- 0.1% for 50Hz nominal
Other Output Voltages
415
Topology
Double Conversion Online
Waveform type
Sine wave
Overload Operation
10 minutes @ 125% and 60 seconds @ 150%
Output Voltage THD
< 2% linear load and <3% non-linear load Output Voltage Tolerance +/-1% static and +/- 5% at 100% load step Transfer Time 2ms typical Bypass Built-in Static Bypass Input Input frequency 40 – 70 Hz (auto sensing) Input voltage range for main operations 340 – 460 (400V), 408 – 552 (480)V Input Total Harmonic Distortion Less than 5% for full load Type of Input Protection Required 3-pole breaker Other Input Voltages 415 Maximum Short Circuit Withstand (Icw) 50.0kAmps Input Power Factor at Full Load 0.99 Batteries & Runtime Battery type VRLA Included Battery Modules 8 Typical recharge time 3.5hour(s) RBC Quantity 6 Extendable Run Time 1 Battery Volt-Amp-Hour Capacity 41472 Extended Run Options Symmetra-PX-125kW-Scalable-to-500kW-without-Maintenance-Bypass-Distribution-Parallel-Capable Efficiency in Battery Operation 96.0 % Overload Operation 10 minutes @ 125% and 60 seconds @ 150% Runtime View Runtime Graph View Runtime Chart Efficiency View Efficiency Graph Communications & Management Interface Port(s) SYPX250-500_Parallel Pre-Installed SmartSlot™ Cards AP9635 Control panel Touch Screen LCD User Interface Emergency Power Off (EPO) Optional Available SmartSlot™ Interface Quantity 1 Physical Maximum Height 78.39inches (1991MM, 199.1CM) Maximum Width 100.39inches (2550MM, 255.0CM) Maximum Depth 42.13inches (1070MM, 107.0CM) Net Weight 6014.8lbs. (2734.0KG) Shipping weight 6679.2lbs. (3036.0KG) Shipping Height 84.65inches (2150MM, 215.0CM) Shipping Width 117.72inches (2990MM, 299.0CM) Shipping Depth 50.0inches (1270MM, 127.0CM) Color Black Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 0 – 95 % Operating Elevation 0-3333ft (0-999.9meters) Storage Temperature -15 – 40 °C Storage Relative Humidity 0 – 95 % Storage Elevation 0-50000ft (0-15000meters) Audible noise at 1 meter from surface of unit 54.0dBA Online thermal dissipation 19427.0BTU/hr Protection Class NEMA 1, IP 20 Conformance Approvals cUL Listed, CSA C22.2 No.107.3-05, EN/IEC 62040-1-1, EN/IEC 62040-2, EN/IEC 62040-3, Eurobat General Purpose, OSHPD, UL 1778, UL 60950-1, UL Listed Sustainable Offer Status Proposition 65 Warning Available in Documentation tab Documentation Manuals and Warranties Symmetra PX 250/500 kW Earthing Principles Containing information on Earthing Principles according to IEC 60364
