Output
Max Configurable Power (Watts)
40.0kWatts / 40.0kVA
Output Voltage Distortion
Less than 5%
Output Frequency (sync to mains)
57 – 63 Hz for 60 Hz nominal
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal
Topology
Double Conversion Online
Waveform type
Sine wave
Maximum Output Current
111
Bypass
Built-in Static Bypass
Input
Input frequency
50/60 Hz
Input voltage range for main operations
177 – 240V
Number of Power Cords
1
Input Power Factor at Full Load
0.99
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules
2
Typical recharge time
2hour(s)
Replacement Battery
SYBT4
Battery Slots Empty
2
Extendable Run Time
1
Battery Volt-Amp-Hour Capacity
5529
Extended Run Options
Symmetra-PX-20kW-Scalable-to-40kW-N-1-208V
Runtime
View Runtime Graph
View Runtime Chart
Efficiency
View Efficiency Graph
Communications & Management
Interface Port(s)
DB-9 RS-232, SmartSlot
Pre-Installed SmartSlot™ Cards
AP9630MPSY3
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO)
Yes
Available SmartSlot™ Interface Quantity
2
Physical
Maximum Height
81.5inches (2070MM, 207.0CM)
Maximum Width
23.62inches (600MM, 60.0CM)
Maximum Depth
35.5inches (902MM, 90.2CM)
Net Weight
1165.0lbs. (529.55KG)
Shipping weight
1291.0lbs. (586.82KG)
Shipping Height
91.0inches (2311MM, 231.1CM)
