Output
Max Configurable Power (Watts)
40.0kWatts / 40.0kVA
Output Voltage Distortion
Less than 5%
Output Frequency (sync to mains)
57 – 63 Hz for 60 Hz nominal
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal
Topology
Double Conversion Online
Waveform type
Sine wave
Maximum Output Current
111
Bypass
Built-in Static Bypass
Input
Input frequency
50/60 Hz
Input voltage range for main operations
177 – 240V
Number of Power Cords
1
Input Power Factor at Full Load
0.99
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules
3
Typical recharge time
2hour(s)
Battery Slots Empty
1
Extendable Run Time
1
Battery Volt-Amp-Hour Capacity
8294
Extended Run Options
Symmetra-PX-30kW-Scalable-to-40kW-N-1-208V
Runtime
View Runtime Graph
View Runtime Chart
Efficiency
View Efficiency Graph
Communications & Management
Interface Port(s)
DB-9 RS-232, SmartSlot
Pre-Installed SmartSlot™ Cards
AP9630MPSY3
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO)
Yes
Available SmartSlot™ Interface Quantity
2
Physical
Maximum Height
81.5inches (2070MM, 207.0CM)
Maximum Width
23.62inches (600MM, 60.0CM)
Maximum Depth
35.5inches (902MM, 90.2CM)
Net Weight
1435.0lbs. (652.27KG)
Shipping weight
1585.0lbs. (720.45KG)
Shipping Height
91.0inches (2311MM, 231.1CM)
Shipping Width
29.5inches (749MM, 74.9CM)
Shipping Depth
41.5inches (1054MM, 105.4CM)
Color
Black
Units per Pallet
1.0
Environmental
Operating Temperature
32 – 104 °F (0 – 40 °C)
Operating Relative Humidity
0 – 95 %
Operating Elevation
0-10000ft (0-3000meters)
Storage Temperature
-15 – 40 °C
