Output
Max Configurable Power (Watts)
500.0kWatts / 500.0kVA
Output Voltage Distortion
Less than 2%
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal, 50Hz +/- 0.1% for 50Hz nominal
Other Output Voltages
380, 415
Topology
Double Conversion Online
Waveform type
Sine wave
Overload Operation
10 minutes @ 125% and 60 seconds @ 150%
Output Voltage THD
< 2% linear load and <3% non-linear load Output Voltage Tolerance +/-1% static and +/- 5% at 100% load step Transfer Time 2ms typical Bypass Built-in Maintenance Bypass, Built-in Static Bypass Input Input frequency 40 – 70 Hz (auto sensing) Input voltage range for main operations 340 – 460 (400V), 408 – 552 (480)V Input Total Harmonic Distortion Less than 5% for full load Type of Input Protection Required 3-pole breaker Other Input Voltages 415 Maximum Short Circuit Withstand (Icw) 50.0kAmps Input Power Factor at Full Load 0.99 Batteries & Runtime Battery type VRLA Included Battery Modules 32 Typical recharge time 3.5hour(s) RBC Quantity 6 Extendable Run Time 1 Battery Volt-Amp-Hour Capacity 165888 Extended Run Options Symmetra-PX-500kW-Scalable-to-500kW-with-Right-Mounted-Maintenance-Bypass-and-Distribution Efficiency in Battery Operation 96.0 % Overload Operation 10 minutes @ 125% and 60 seconds @ 150% Runtime View Runtime Graph View Runtime Chart Efficiency View Efficiency Graph Communications & Management Pre-Installed SmartSlot™ Cards AP9635 Control panel Touch Screen LCD User Interface Emergency Power Off (EPO) Optional Available SmartSlot™ Interface Quantity 1 Physical Maximum Height 78.39inches (1991MM, 199.1CM) Maximum Width 204.72inches (5200MM, 520.0CM) Maximum Depth 42.13inches (1070MM, 107.0CM) Net Weight 18746.2lbs. (8521.0KG) Shipping weight 20490.8lbs. (9314.0KG) Shipping Height 84.65inches (2150MM, 215.0CM) Shipping Width 279.53inches (7100MM, 710.0CM) Shipping Depth 50.0inches (1270MM, 127.0CM) Color Black Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 0 – 95 % Operating Elevation 0-3333ft (0-999.9meters) Storage Temperature -15 – 40 °C Storage Relative Humidity 0 – 95 %
