CPU
Chipset AMD B450
CPU Socket AM4
Back Panel I/O
USB 1 x USB 3.1 Gen 2 Type-A
1 x USB 3.1 Gen 1 Type-C
2 x USB 3.1 Gen 1 Type-A
2 x USB 2.0 Type-A
Display 1 x DVI-D
1 x HDMI 2.0
Audio 3 x 3.5 mm
Ethernet / Controller 1 x Realtek 8111H Gigabit
PS/2 1 x Combo
Memory
Memory Slots 4 x 288-Pin
Memory Support DDR4 2133, 2400, 2666, 2800, 3000, 3200 MHz
Maximum Capacity 64 GB
Channel Architecture Dual Channel
ECC Support Non-ECC Unbuffered
Storage Expansion
SATA 6 x SATA III
M.2 1 x M Key 2242, 2260, 2280 (PCIe 3.0 x4, SATA III)
U.2 None
Optane Memory Support No
Internal I/O
Expansion Slots 1 x PCIe 3.0 x16
1 x PCIe 2.0 x16
1 x PCIe 2.0 x1
USB 1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port)
2 x USB 2.0 Header (Supports 4 USB Type-A Port)
Multi-GPU Support 2-Way AMD CrossFireX
Air Cooling 1 x 4-Pin CPU
2 x 4-Pin System
Power Connectors 1 x 24-Pin Mainboard
1 x 8-Pin CPU
LED Header 1 x RGB
Audio None
Diagnostics Clear CMOS
Legacy 1 x Serial
BIOS
ROM 128 Mb
Front Panel I/O
I/O Connection Headers AAFP, USB 3.1
Audio
Audio Codec Realtek ALC887 (8-Channel)
Software
Supported Operating Systems Windows 10 (64-Bit)
Physical
Form Factor Micro-ATX
Dimensions 9.6 x 9.6″ / 243.84 x 243.84 mm
