Bay Provided
Form Factor :2.5″
Free Qty :2
Total Qty :2 Bays
Cache Memory
Installed Size :4 MB
Per Processor Size :4 MB
Type :L3 cache
Chassis
Form Factor :Blade Server
Hot-Swap Bays Qty :2
Manufacturer Form Factor :Blade
Server Storage Bays :Hot swap
Server Swappable Drive Form Factor :2.5″
Server Swappable Drive Form Factor (metric) :6.4 cm
Server Swappable Drive Interface :SATA/SAS
Dimensions & Weight
Depth :7.5 in
Height :1.6 in
Weight :2.43 lbs
Width :7.4 in
Display
Type :None.
Environmental Parameters
Humidity Range Operating :5 – 95%
Max Operating Temperature :104 °F
Min Operating Temperature :32 °F
Expansion Bays
Form Factor (metric) :6.4 cm
Type :Hot-swap
Expansion Slots
Type :CPU
Type :DIMM 240-pin
Type :SD card
Hard Drive
Type :Flash
Hard Drive (3rd)
Type :None
Header
Brand :Cisco
Compatibility :PC
Manufacturer :CISCO DS HARDWARE DIRECT
Model :EN120S M2
Packaged Quantity :1
Product Line :Cisco UCS Network Compute Engine
Interface Provided
Connector Type :RJ-45
Type :Management (NIC)
Qty :1
Type :KVM
Type :LAN (Gigabit Ethernet)
Type :USB 2.0
Miscellaneous
Color Category :Gray
Compliant Standards :AS/NZS 60950-1, BSMI CNS 13438 Class A, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, EN 300386, EN 60950-1 Second Edition, EN 61000-6-1, EN50082-1, EN55022 Class A, EN55024, FCC CFR47 Part 15, ICES-003 Class A, IEC 60950-1 Second Edition, UL 60950-1 Second Edition, VCCI V-3
Networking
Data Link Protocol :Ethernet, Fast Ethernet, Gigabit Ethernet
Form Factor :Integrated
Remote Management Controller :Cisco Integrated Management Controller
Remote Management Protocol :CLI, HTTP, IPMI 2.0
Optical Storage
Drive Type :No optical drive
Type :None
Optical Storage (2nd)
Type :None
Printer
Type :None
Processor
Clock Speed :2 GHz
Installed Qty :1
Manufacturer :Intel
Max Supported Qty :1
Number of Cores :Dual-Core
Processor Main Features :Hyper-Threading Technology, Intel Virtualization Technology
Processor Number :B925C
Type :Pentium
