Bay Provided
Form Factor :2.5″ SFF
Free Qty :2
Total Qty :2 Bays
Cache Memory
Installed Size :22 MB
Installed Size :22
Per Processor Size :11 MB
Per Processor Size :11
Card Reader
Supported Flash Memory Cards :SD Memory Card
Chassis
Form Factor :Blade
Front Accessible Bays Qty :2
Hot-Swap Bays Qty :2
Internal Bays Qty :2
Manufacturer Form Factor :Blade Server
Server Storage Bays :Hot swap
Server Swappable Drive Form Factor :2.5″
Server Swappable Drive Form Factor (metric) :6.4 cm
Server Swappable Drive Interface :SATA/SAS
Dimensions & Weight
Depth :24.4 in
Height :2 in
Weight :9.5 lbs
Width :8 in
Display
Type :None.
Environmental Parameters
Humidity Range Operating :5 – 93% (non-condensing)
Max Operating Temperature :95 °F
Min Operating Temperature :50 °F
Expansion Bays
Form Factor (metric) :6.4 cm SFF
Type :Hot-swap
Expansion Slots
Type :CPU
Type :DIMM 288-pin
Type :Expansion slot
Type :M.2 Card
Type :mLOM
Type :SD card
Hard Drive
Type :No HDD
Hard Drive (2nd)
Type :None
Hard Drive (3rd)
Type :None
Header
Brand :Cisco
Compatibility :PC
Manufacturer :Cisco Unified Computing
Model :SmartPlay Select B200 M5 Basic 1
Packaged Quantity :1
Product Line :Cisco UCS
Interface Provided
Location :1 internal
Type :USB 3.0
Qty :1
Type :KVM
Type :VGA
Mainboard
Processor Socket :Socket P
Miscellaneous
Color Category :Gray
Compliant Standards :ACPI 4.0
Included Accessories :2 x blanking panels, 2 x CPU Heatsink, 20 x DIMM blanks
Networking
Data Link Protocol :40 Gigabit Ethernet, 40Gb Fibre Channel over Ethernet (FCoE)
Ethernet Controller(s) :Cisco UCS Virtual Interface Card 1340
Remote Management Controller :Cisco Integrated Management Controller
Optical Storage
Drive Type :No optical drive
Type :None
Optical Storage (2nd)
Type :None
OS Provided
Type :No operating system
Printer
Type :None
Processor
Clock Speed :1.7 GHz
Installed Qty :2
Manufacturer :Intel
Max Supported Qty :2
Number of Cores :8-core
Processor Number :3106
Server Scalability :2-way
Type :Xeon Bronze
Upgradability :Upgradable
