Dimensions & Weight
Depth :30 in
Height :1.7 in
Width :17.3 in
Environmental Parameters
Humidity Range Operating :5 – 95% (non-condensing)
Humidity Range Storage :5 – 95% (non-condensing)
Max Operating Temperature :104 °F
Max Storage Temperature :158 °F
Min Operating Temperature :32 °F
Min Storage Temperature :-40 °F
Header
Brand :Cisco
Compatibility :PC
Manufacturer :Cisco Unified Computing
Model :SmartPlay Select
Model no: 6248UP
48-Port Fabric Interconnect
Packaged Quantity :2
Product Line :Cisco UCS
Interface Provided
Comments :Management
Connector Type :RJ-45
Qty :1
Type :1000Base-T
Connector Type :SFP+
Qty :32
Miscellaneous
Color Category :Blue
Compliant Standards :AS/NZS 60950-1, BSMI CNS 13438 Class A, CAN/CSA-C22.2 No. 60950-1, CISPR 22, CISPR 24, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN50082-1, EN55022 Class A, EN55024, FCC CFR47 Part 15, GB 4943, ICES-003 Class A, IEC 60950-1, RoHS, UL 60950-1
Height (Rack Units) :1U Rack Mount
Networking
Compliant Standards :IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3ae
Features :Data Center Bridging Exchange (DCBX) support, IGMP snooping, Layer 2 switching, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+)
Form Factor :Rack-mountable
Jumbo Frame Support :9216 bytes
MAC Address Table Size :32000 entries
Manageable :Yes
Ports Qty :32
Remote Management Protocol :RMON
Subcategory :Network hubs and switches
Subtype :10 Gigabit Ethernet
Type :Switch
Performance
Type :Throughput
Value :960 Gbps
Ports
Qty :12
Type :10 Gigabit / FCoE SFP+
Power Device
Hot-Plug :Hot-plug
Installed Qty :0
Max Supported Qty :2
Power Redundancy :Optional
Power Redundancy Scheme :1+1 (with optional power supply)
Type :Internal power supply
