Manufacturer: Ubiquiti Networks
Brand: Ubiquiti
Dimensions: 76.5 x 76.5 x 26.8 mm (3.01 x 3.01 x 1.06″)
Weight: 70 g (2.47 oz)
Networking Interfaces:
– (1) 1 Gbps SFP Port
– (1) 10/100/1000 Mbps RJ45 Port
Power Method:
– 802.3af PoE: (Pins 1, 2+; 3, 6-)
– 24V Passive PoE: (Pins 4, 5+; 7, 😎
Power Supply: 802.3af PoE or 24V Passive PoE Device
Max. Power Consumption: 1.5W
Supported Voltage Range: 16 to 57V
LEDs:
– 1x Ethernet
– 1x Optical Signal
– 1x Power
Operating Temperature: -40 to 60° C (-40 to 140° F)
Operating Humidity: 10 to 90% Noncondensing
ESD/EMP Protection: ± 12kV Contact/Air
Certifications: CE, FCC, IC
