Output
Max Configurable Power (Watts)
1.8kWatts / 2.0kVA
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
Load Crest Factor
3 : 1
Topology
Double Conversion Online
Waveform type
Sine wave
Bypass
External Manual Bypass, Internal Bypass (Automatic and Manual)
Input
Input frequency
40 – 70 Hz (auto sensing)
Input voltage range for main operations
85 – 155V
Number of Power Cords
1
Batteries & Runtime
Battery type
No internal battery – uses external battery system
Nominal Battery Voltage
48V
Extended Run Options
APC-SmartUPS-Industrial-2000VA-1800W-120VAC-In-Out-RM-Conformal-Coated
Efficiency in Battery Operation
88.0 %
Communications & Management
Control panel
Multi-function LCD status and control console
Audible Alarm
Audible and visible alarms prioritized by severity
Surge Protection and Filtering
Surge energy rating
432Joules
Physical
Maximum Height
3.46inches (88MM, 8.8CM)
Maximum Width
17.01inches (432MM, 43.2CM)
Maximum Depth
10.24inches (260MM, 26.0CM)
Net Weight
22.05lbs. (10.0KG)
Shipping weight
26.46lbs. (12.0KG)
Shipping Height
7.32inches (186MM, 18.6CM)
Shipping Width
21.06inches (535MM, 53.5CM)
Shipping Depth
14.57inches (370MM, 37.0CM)
Environmental
Operating Temperature
-40 – 165.2 °F (-40 – 74 °C)
Operating Relative Humidity
0 – 95 (non-condensing) %
Operating Elevation
0-10000ft (0-3000meters)
Storage Temperature
-40 – 85 °C
Storage Relative Humidity
0 – 95 (non-condensing) %
Storage Elevation
0-50000ft (0-15000meters)
Audible noise at 1 meter from surface of unit
55.0dBA
Protection Class
IP 20
